TANKS
HORIZONTAL TANKS
These are underground septic and water tanks with a “horizontal design”. The diameter of these tanks spans from 48 to 102 inches, specifically engineered for burial at depths ranging from 7 to 10 feet below the surface.
The product line encompasses capacities ranging from 500 to 10,000 gallons.
Horizontal Style Underground Tanks
“Potable” Water Models
48” Diameter (4`)
48UG500HDW – 88” long, 500 gallons, (great for high water tables, or rocky soil)
48UG1000HDW – 162” long, 1000 gallons, (great for high water tables, or rocky soil)
72” Diameter (6`)
72UG1500HDW – 114” Long 1500 gallon water tank
72UG2000HDW – 152” Long 2000 gallon water tank
72UG2500HDW – 190″ Long 2500 gallon water tank
96” Diameter (8`)
96UG3500MDW or HDW – 168” Long 3500 gallon water tank
96UG4000MDW or HDW – 201”`Long 4000 gallon water tank
96UG5000MDW or HDW– 234” Long 5000 gallon water tank
102” Diameter (8` 6”)
102UG6000HDW – 226″ Long 6000 IMP gallon water tank
102UG6500HDW – 232″ Long 6500 IMP gallon water tank
102UG7500HDW – 275″ Long 7500 IMP gallon water tank
102UG8400HDW – 300” Long 8400 IMP gallon water tank
102UG10000MDW – 356” Long 10,000 IMP gallon water tank
C.S.A approved Horizontal Sewage Models
48” Diameter (4`)
48UG500HDS – 88″ Long 500 gallon sewage tank
48UG500HDT – 88″ Long, 500 gallon sewage tank (outhouse version)
48UG1000HDS – 162″ Long 1000 gallon sewage tank
48UG1000HDT – 162″ Long 1000 gallon sewage tank (outhouse version)
72” Diameter (6`)
72UG1500HDS – 114″ Long 1500 gallon sewage tank
72UG1500HDP -114″ Long 1500 gallon two compartment
(pumpout)
72UG2000HDS – 152″ Long 2000 gallon sewage tank
72UG2000HDP – 152″ Long 2000 gallon two compartment
(pumpout)
84” Diameter (7`)
84UG3600HDP – 192” Long 3600 gallon two compartment tank
(pumpout)
84UG4800HDP – 247” Long 4800 gallon two compartment tank
(pumpout)
84UG6000HDP – 306” Long 6000 gallon two compartment tank
(pumpout)
96” Diameter (8`)
96UG3500MDS – 168” Long 3500 gallon sewage tank
96UG5000MDS – 226” Long 5000 gallon sewage tank
102” Diameter (8`6”)
102UG6150HDS – 228″ Long 6150 Imp gallon sewage holding tank (Heavy Duty)
102UG7900HDS – 288” Long 7900 Imp gallon sewage tank (Heavy Duty)
102UG8400HDS – 300” Long 10000 gallon sewage tank (Heavy Duty)
102UG10000HDS – 356” Long 10000 gallon sewage tank (Heavy Duty)
MDS = Medium duty (7 feet of earth cover on top of tank allowed)
HDS = Heavy Duty (10 feet of earth cover on top of tank allowed)
HDP = Pumpout (Also Known As a “two compartment” 10′ of earth cover allowed)
Top ten reasons why to buy an exceptional “Horizontal” sewage/ water tank from PYW
# 10) Easy to install
# 9) Bonded together
# 8) Non-filled resin for maximum strength
# 7) It will not rust, rot, or corrode
# 6) Integral Lifting Lugs
# 5) 5 Year Warranty
# 4) 8″ child proof access opening on lid
# 3) Factory Assembled
# 2) Proven Design
# 1) Reason to buy these exceptional tanks from PYW……They work fantastic!
DROP AND GO TANKS
Explore our “Drop & Go” easy burial tanks, crafted for uncomplicated installation and user-friendly assembly, enabling convenient do-it-yourself setup.
These tanks require no special backfill, and their flat bottom ensures precise and level placement. The lightweight fiberglass construction adds to their appeal, making them highly sought-after.
You can rely on their consistent availability in stock, ensuring convenience for your project needs.
Drop and Go
1000 Gallon Fiberglass Tanks – C.S.A. Approved
75H1000MDS, Sewage holding tank, 1000 gallons
75H1000HDS, Sewage holding tank, 1000 gallons (Heavy Duty)
75P1000MDS, 2 compartment septic tank, 1000 Gallons (750 gallon working capacity)
75P1000HDS, 2 compartment septic tank, 1000 Gallons (750 gallon working capacity) Heavy Duty 75S1000MDS, 2 compartment siphon tank, 1000 Gallons (750 gallon working capacity)
75S1000HDS, 2 compartment siphon tank, 1000 Gallons (750 gallon working capacity) Heavy Duty 75T1000MDS, 2 compartment trickle tank, 1000 Gallons (750 gallon working capacity) 75T1000HDS, 2 compartment trickle tank, 1000 Gallons (750 gallon working capacity) Heavy Duty
“Drop and Go” – Water
75W1000MDW, 75W1000HDW – A water tank
Abbreviation explanation:
MDS = Medium duty (7 feet on top of tank allowed)
HDS = Heavy Duty (10 feet on top of tank allowed)
Height = 84”
Diameter = 81”
Inlet = 4” on (sewage only)
Volume = 1,000 Gallons
Top ten reasons why to buy an exceptional “Drop and Go” sewage/ water tank from PYW
# 10) Lightweight 320 pounds
# 9) Up to 7 ft. backfill on top of Medium duty tanks, 10 ft. on Heavy duty
# 8) CSA Approved (Sewage models)
# 7) It will not rust, rot, or corrode
# 6) Water tested
# 5) 5 year Warranty
# 4) 8” child proof access opening on lid
# 3) Factory assembled
# 2) No special back fill required
# 1) Reason to buy this exceptional tank from PYW………Easy to install!
BOLT TOGETHER TANKS
Introducing our “Bolt Together” potable water tanks—an essential lifeline during water crises.
Safeguard yourself with 750 gallons of secure, drinkable water in your basement, easily achievable with our innovative design. Fear not, as all bolt-together sections effortlessly fit through your front door. Prepare for the worst with the ability to store a staggering 1850 gallons in one tank, ensuring resilience during unsettling “Boil Water” advisories.
This product line is your fortification against uncertainty, offering peace of mind for disaster or emergency scenarios.
Bolt Together Tanks
Potable Water Tanks
Round 48” Diameter style
48BTO150 – 1 piece, 24” tall 150 gallons
48BTC150 – 2 piece, 24” tall 150 gallons (With Lid)
48BTC300 – 2 piece, 48” tall 300 gallons
48BTC450 – 3 piece, 72” tall 450 gallons
48BTC600 – 4 piece, 96” tall 600 gallons
Round 60” Diameter style
60BTO250 – 1 piece, 24” tall 250 gallons
60BTC250 – 2 piece, 24” tall 250 gallons (With Lid)
60BTC500 – 2 piece, 48” tall 500 gallons
60BTC750 – 3 piece, 72” tall 750 gallons
60BTC1000 – 4 piece, 96” tall 1000 gallons
Round 96” Diameter
96BTO750 – 1 piece, 30” tall, 750 gallons
96BTC750 – 1 piece, 30” tall, 750 gallons (With Lid)
96BTC1500 – 2 piece, 60” tall, 500 gallons
96BTC2250 – 3 piece, 90” tall, 2250 gallons
96BTC3000 – 4 piece, 120” tall, 3000 gallons
96BTC3750 – 5 piece, 150” tall, 3750 gallons
96BTC4500 – 6 piece, 180” tall, 4500 gallons
Oval Styles
72BTO650 – 1 piece, 72” Length, 30” Height, 102” Width, 650 gallons
72BTC650 – 2 piece, 72” Length, 30” Height, 102” Width, 650 gallons (With Lid)
72BTC1250 – 2 piece, 72” Length, 60” Height, 102” Width, 1250 gallons
72BTC1850 – 3 piece, 72” Length, 90” Height, 102” Width, 1850 gallons
AGW-OV150 – 1 piece, 69” Length, 28” Height, 32” Width, 150 gallons
AGW-OV300 – 2 piece, 69” Length, 56” Height, 32” Width, 300 gallons
Top ten reasons why to buy an exceptional “Bolt Together” water tank from PYW
# 10) Versatile
# 9) Stackable, saving you valuable floor space
# 8) They look fantastic
# 7) They will not rust, rot, or corrode
# 6) Water tested
# 5) 5 year Warranty
# 4) 15” lid with air vent
# 3) Comes with bolts, gaskets, standard 1 ¼” outlet
# 2) Smooth inside makes them easy to clean
# 1) #1 Reason to buy this exceptional tank from PYW…Can pass through your front door!
Choose from our range of dimensions:
38″ x 38″ x 12″ tall, ideal for concealing a standard 36″ concrete lid.
42″ x 42″ x 18″ tall, perfect for covering a taller concrete lid with an adjacent power box.
Elevate the visual appeal of your space with our aesthetically pleasing and expertly crafted faux rock septic covers.
FAUX ROCKS
Conceal those unsightly septic tank lids effortlessly with faux rocks from Progressive Yard Works Ltd.
Do you find yourself grappling with the challenge of hiding a visually unappealing septic tank cover? Whether you’ve recently acquired a lakeside property for your cabin or your existing septic tank cover is a source of aesthetic discomfort, we have the perfect solution. Our specially designed faux rock covers, crafted from durable fiberglass, seamlessly camouflage most septic tank lids. Backed by extensive customer research, these faux rock septic covers have been a hallmark of our manufacturing prowess in Saskatoon for 18 years.
Septic rock cover (12″ tall) $499.00 (38″’ x 38’ x 12″)
Septic rock cover (18″ tall) $499.00 (42’ x 42″ x 18″)
AQUACULTURE TANKS
CUSTOM TANKS
If you’re in search of a tailored tank solution, your quest ends here.
Our expertise is evident in the numerous inquiries we receive weekly, as businesses seek our proficiency in constructing custom tanks. Whether it’s above-ground verticals, custom sumps, or any specialized fabrication, let us assist you.
Drop by our facility or give us a call to initiate a discussion about fulfilling your unique requirements.
